Laird S8655PL-RASF “Mini” Outdoor Antenna – LHCP (ETSI)

$165.00

Spec Sheet


Description

The Laird Technologies’ S8655PL is the latest addition to the high-performance RFID antenna lineup and is the only UHF RFID antenna available to the market that offers no-compromise performance in a small package. At only 5.2” square the antenna offers a gain specification of 5.5 dBic and axial ratio better than 2 dB.

In effect the antenna is providing the performance one would expect of a much larger antenna. The antenna is not only mechanically robust but is less likely to be exposed to excessive damage by virtue of its reduced size.

∗There are NO cables included when purchased. Cables MUST be purchased Separately. For help, please either call or email us and a member of the Gateway team will assist you with any of your purchasing needs.

∗∗This Antenna is LEFT HAND CIRCULAR POLARIZED. Operation is within the European Telecommunications Standards Institute range of 865-868 MHz.

Brief Specifications

  • Applications: Warehouse; Distribution center; Airports and hospitals; Transit terminals; Conveyor belts
  • Frequency: 865-868 MHz
  • Polarization: Left Hand Circular Polarized (LHCP)
  • Gain: 5.5 dBic
  • Size: 5.2 x 5.2 x .71 (in); 386 x 386 x 18 (mm)
  • Connector: Type N Female
  • IP Rating: IP 67

Why buy the Laird S8655PL?

The Laird S8655PL Outdoor Antenna offers exceptional read range for its size. It also sports an IP rating of 67 which makes it suitable for harsh environments.

If interested in purchasing in volume, please either call or email us about your order. Volume discounts apply.

Additional information

Weight .8 lbs
Dimensions 6 × 4.5 × 4.5 in
