Spec SheetDescription
The Laird Technologies’ PAR90209H antenna is a circularly polarized panel antenna that provides reception and transmission of signals in the 902-928 MHz frequency band. Laird Technologies’ industry-renowned design methodology achieves maximum efficiency and performance across the entire frequency band. Both VSWR and axial ratios are excellent and allow the user to achieve the maximum performance for an antenna of this type. The antenna is housed in a heavy duty radome enclosure that can be directly wall mounted. An optional articulating mount allows either wall or mast mounting. The antenna is offered with an integrated fixed connector with a variety of connector types.
∗There are NO cables included when purchased. Cables MUST be purchased Separately. For help, please either call or email us and a member of the Gateway team will assist you with any of your purchasing needs.
∗∗This Antenna is RIGHT HAND CIRCULAR POLARIZED. Operation is within the Federal Communications Commissions range of 902-928 MHz.
Brief Specifications
- Applications: Warehouse; Distribution center; Airports and hospitals; Transit terminals; Conveyor belts
- Frequency: 902-928 MHz
- Polarization: Right Hand Circular Polarized (RHCP)
- Gain: 9 dBi
- Size: 10.2 x 10.2 x 1.32 (in); 259 x 259 x 33.5 (mm)
- Mounting: Threaded stud
- Connector: Type N Female
- IP Rating: IP 67
- Operating Temperature: -25° to +70°C
Why buy the Laird 9025PR?
The Laird PAR90209H Circular Polorized Outdoor Antenna has a high gain, along with being rugged and weatherproof.
If interested in purchasing in volume, please either call or email us about your order. Volume discounts apply.
